Miyanaga Dressing Plate - DDP

There are no reviews yet. | Write a review
Price: FREE
    Availability: In Stock
    Usually ships In 1-2 Business Days
    Item #: DDP

    CHARACTERISTICS
    • Easily drills into difficult-to-cut materials such as porcelain tile.
    • Excellent durability. Automatic water supply to the cutting edge (with a built-in water tank)
      *Enabled when the revolution per minutes (RPM) of the electric drill is 1000 to 3000 rpm.
      No water is supplied when the RPM is other than above range.
    • Usable with impact drivers, which allow cordless and easy operation.
    • Individually replaceable cutter delivers cost saving.
    APPLICATIONS
    • Porcelain tile and Ceramic tile.
    • Granite and Marble.
    Cutter diameter :5/32" to 3/8" (4.0 to 10.0mm)
    Max.drilling depth :1-3/8" (35mm)
    Shank size :1/4" hexagonal shank (6.35mm) (DIN3126,ISO1173 style E6.3)
    Optimum rotation :1000-3000 r.p.m (double insulated,in the rotary-only mode)
